Omni Corneal Cross Linking System
A clinically proven UV light–based system designed to halt the progression of keratoconus and other ectatic disorders. It strengthens the cornea using controlled UV energy with advanced features such as eye tracking, self-calibration, and adjustable radiation modes for safe and effective cross-linking treatment.
Cross Linking: The Science Behind the Treatment
Corneal Cross Linking is a treatment designed to strengthen the corneal stroma by creating new chemical bonds between collagen fibers through the application of UV light and a photosensitizer. It is the only proven method to stop the progression of keratoconus and related ectatic disorders such as PMD and iatrogenic ectasia, while also helping stabilize corneal topography.
Modern collagen cross-linking techniques were developed in Europe in the late 1990s, and early human studies of UV-induced corneal crosslinking consistently showed positive results. Clinical trials demonstrated significant improvement in corneal curvature, increased corneal strength, and stabilization of progressive keratoconus. Today, Omni Cross Linking systems are used worldwide and continue to be a reliable, evidence-based solution for patients with corneal ectasia.
Key Features
The Omni Cross Linking System has been designed with a strong focus on clinical effectiveness, safety, and ease of use. Its advanced optical system ensures uniform UV illumination across the treatment zone, while automated controls maintain consistent and accurate energy delivery throughout the procedure.
- Variable UV energy settings from 3 mW to 45 mW with automatic time adjustment
- Continuous, pulsed, and LASIK radiation modes
- Self-calibrating and self-adjusting operation
- Integrated infrared eye-tracking system
- Optional built-in pachymeter for corneal thickness measurement
Technical Specifications
| Wavelength | 365 nm |
| Irradiating Intensity | Adjustable from 3 – 45 mW/cm² |
| Radiation Modes | Continuous, Pulsed, LASIK (ALSK) Mode |
| Working Distance | 50 mm ± 5 mm |
| Aperture Size | 1 – 11 mm |
| Timers | Automatic time adjustment with audible indication |
| Eye Tracking | Integrated infrared eye-tracking system |
| Pachymeter | Optional integrated corneal thickness measurement |
| Power Supply | 100–240V, 50/60 Hz |
| Dimensions | 28.5 × 25.5 × 10 cm |
| Weight | 1.8 kg |
Clinical Experience
Extensive clinical studies have demonstrated the effectiveness and long-term stability of corneal cross linking for treating progressive keratoconus and ectatic disorders. Research consistently shows improvements in corneal curvature, increased biomechanical strength, and stabilization of disease progression following treatment.
Over the past two decades, thousands of successful procedures worldwide have validated the safety and reliability of UV-induced corneal crosslinking. The Omni Cross Linking System incorporates this proven scientific foundation and enhances it with modern treatment control, ensuring both precision and predictable patient outcomes.
